Security Doors

1

MCA CTK

is particularly suitable for implementations which need two passages fitted with interlocking motorized doors to
check the access of people in narrow spaces. With an overall dimension of 1800 x 1050 mm it's possible to use 2 separate
passages , usable in entry and exit or both ways able to check the people in transit if allowed or not to pass through. Elegant
and strong, MCA CTK is easy to be placed in any site. It's just provided in assembly kit to make the application easier and
effected in short time and immediately ready to be used.
Dimensions: 1800 x 1050 x 2320 mm Weight: from 1200 to 1400 kg depending on the type of glass used cabine entrance size:
2 x 600 x 2100 mm
Some equipment which can be provided: Metal Detector - Stainless Steel Finish - Interface with access control - Transit
control of single person - Mechanical Lock for night closure - Intercommunicate system fitted with control station.
Sensors for automatic opening of wings - unblocking button for emergency

2

MCA CSK

MCA CSK is a strong and elegant item, particularly suitable for implementations which need to control the access of people in
security areas through interlocking motorized doors in a fast way making a physical barrier in favour of security and weather
resistance. With an overall dimension of 1050 mm it's available a controlled passage usable for entry, exit or both ways ables
to manage the people in transit if are allowed or not to pass through. Elegant and strong, MCA CSK is easy to be placed in any
site. It's provided pre-assembled or in assembly kit to make the application into the destination sites easier. It's assembled in
short time and is immediately ready to be used.

"Dimensions: 1050 x 2320 mm Weight: from 750 to 850 kg depending on the type of glass used cabine entrance size: 600 x
2100 mm"
Some equipment which can be provided: Metal Detector - Stainless Steel Finish - Interface with access control - Transit control
of single person - Mechanical Lock for night closure - Intercommunicate system fitted with control station. Sensors for
automatic opening of wings - unblocking button for emergency

3

MCA CMK

MCA CMK is a strong and elegant product, particularly suitable for implementations which need to control the access of people to security areas through interlocking motorized doors in a fast way making a physical barrier in favour of security and weather resistance. With an overall dimension of 1150 mm it's available a controlled passage usable for entry, exit or both ways ables to manage the people in transit if are allowed or not to pass through. Elegant and strong, MCA CMK is easy to be placed in any site. It's provided pre-assembled or in assembly kit to make the application into the destination sites easier. It's assembled in short time and is immediately ready to be used. Compared to MCA CSK version has got a wider gap by 100 mm.

4

MCA CLK

MCA CLK is a strong and elegant product, particularly suitable for implementations which need to control the access of people to security areas including disabled people in wheelchair through interlocking motorized doors in a fast way making a physical barrier in favour of security and weather resistance. With an overall dimension of 1500 mm it's available a controlled passage usable for entry, exit or both ways ables to manage the people in transit if are allowed or not to pass through and with possibility of special cycle for disabled people. Elegant and strong, MCA CLK is easy to be placed in any site. It's provided pre-assembled or in assembly kit to make the application into the destination sites easier. It's assembled in short time and is immediately ready to be used. Compared to MCA CMK version has got a passage by 900 mm.
Some equipment which can be provided: Metal Detector - Stainless Steel Finish - Interface with access control - Transit control of single person - Mechanical Lock for night closure - Intercommunicate system fitted with control station. Sensors for automatic opening of wings - special cycle for disabled people - transfer of packages/trolleys - unblocking button for emergency

Security Doors

1

MCA QS

MCA QS is a strong and elegant item, particularly suitable for implementations which need to control the access of people to
security areas through interlocking motorized doors in a fast way making a physical barrier in favour of security and impact on the
environement. In square version for implementation in architectural context requiring such feature at a lower cost compared to
the circular version with an overall dimension of 1050 x 1050 mm it's available a controlled gap usable for entry, exit or both
ways ables to manage the people in transit if are allowed or not to pass through. Elegant and strong, MCA QS is easy to be placed
in any site. It's just provided in the pre-assembled mono-block version. Hence it's suggested to make a survey on the installation
site firstly to verify which can be implemented without incurring in any problem.
Dimensions: 1050 x 1050 x 2320 mm Weight: from 750 to 850 kg depending on the type of glass used Cabine entrance size: 600 x
2100 mm
Some equipment which can be provided: Metal Detector - Stainless Steel Finish - Interface with access control - Transit control of
single person - Mechanical Lock for night closure - Intercommunicate system fitted with control station. Sensors for automatic
opening of wings - unblocking button for emergency


2

MCA QM

MCA QM is a strong and elegant product, particularly suitable for implementations which need to control the access of people to
security areas through interlocking motorized doors, in a fast way creating a physical barrier in favour of security and weather
resistance. In square version for implementation in architectural context requiring such feature feature at a lower cost compared
to the circular version with an overall dimension of 1150 x 1150 mm it's available a controlled passage usable for entry, exit or
both ways ables to manage the people in transit if are allowed or not to pass through. Elegant and strong, MCA QM is easty to be
placed in any site. It's just provided in the pre-assembled mono-block version. Hence it's suggested to make a survey on the
installation site firstly to verify which can be implemented without incurring in any problem. Compared to QS version has got a
wider passage by 100nm
Dimensions: 1150 x 1150 x 2320 mm Weight: from 800 to 900 kg depending on the type of glass used Cabine entrance size: 700 x
2100 mm
Some equipment which can be provided: Metal Detector - Stainless Steel Finish - Interface with access control - Transit control of
single person - Mechanical Lock for night-time closure - Intercommunicate system fitted with control station. Sensors for
automatic opening of doors - unblocking button for emergency

3

MCA R1800

MCA R1800 is an item particularly suitable to check accesses in sites with much traffic flow. Through the 3 rotating sectors is able
to make pass until 21 people in one way and until 42 people in both ways. It's made in steel and aluminium frame with wide
surfaces in glass and the top containing the motorization system of very small dimensions further to much accurate finishing. It
looks very elegant in harmony with the sites where is installed. Fitted with proper brushes on the revolving wings it assures an
excellent thermal capacity. The product can be fitted with additional doors self closing in case of presence of a person not
allowed to enter in the rotation sector bringing the person back to the access point without reverting the route. MCA R1800 is
easy to be placed in any site, is just provided in assembly kit, it's assembled quickly in few hours and is just ready to be used, has
no floor, is placed on the floor of the installation' site.
Dimensions: 1800 x 2320 mm Weight: from 1000 to 1200 kg depending on the type of glass used Real crossing light: 750 x
2100 mm
Some equipment which can be provided: - Stainless Steel Finish - Interface with access control - Transit control of single person
- Mechanical Lock for night-time closure - Intercommunicate system fitted with control station. Sensors for automatic opening
of doors - unblocking button in an emergency - access control function - automatic rotation function


4

MCA R2300

 MCA R2300 is an item particularly suitable to check accesses in sites with large flow. Through the 4 rotating sectors is able to
make pass until 28 people in one way and until 56 people in both ways. It's made in steel and aluminium frame with wide
surfaces in glass and the top containing the motorization system of very very small dimensions further to much accurate
finishing. It looks very elegant in harmony with the sites where is installed. Fitted with proper arms on the rotating doors it
assures an excellent thermal capacity. The product can be fitted with additional doors self closing in case an authorised user
attempts to enter to security area bringing him back to the access point without reverting the route. MCA R2300 is easy to be
placed in any site, is just provided in assembly kit, it's assembled quickly in few hours and is just ready to be used, has no floor,
is placed on the floor of the installation' site.
Dimensions: 2300x 2320 mm Weight: from 1300 to 1400 kg depending on the type of glass used Cabine entrance size: 1400 x
2100 mm
Some equipment which can be provided: - Stainless Steel Finish - Interface with access control - Transit control of single person
- Mechanical Lock for night closure - Intercommunicate system fitted with control station. Sensors for automatic opening of
doors - unblocking button in an emergency - access control function - automatic rotation function
